Fire Doors

Fire Doors

Gosport Fire Doors provide up to 4 hours fire resistance in all door configurations whilst maintaining the strength and longevity of our steel heavy duty doors.



Key Features
  • Key Features
  • Up to 4 hour fire resistance (2 hours for double doorsets with vision panels).
  • Tested in accordance with BSEN1634-1:2008 and BSEN1363-1:1999 (exceeds BS476 Part 22 1987).
  • Optional intumescent smoke and draft seal (1 hour fire rated).
  • Optional vision panels (up to 240 minute rated for single doors, up to 120 minute rated for double doors).
  • Optional transfer grilles (fitted in lower half of door).
  • Hinged top panel(s) (no above head height lifting required to open) and removable transom.
  • 2.5mm mild steel facing sheet and mid panel
  • 100x40x2 ERW mild steel door chassis
    100x40x2 ERW mild steel main frame (depending on application, frame material section can be varied to suit)
  • Gosport Heavy Duty Low Maintenance Hinges (Gosport design and manufacture):
    • Mild steel solid body
    • 20mm diameter stainless steel pivot pin incorporating 10mm diameter hardened rotating pin
    • Plain bearing journal (teflon coated phosphor bronze)
    • Phosphor bronze self-lubricating washer
    • Grease nipple for easy maintenance
  • 3 No.12mm diameter dogs to hinge side to prevent doors being lifted off the hinges.
  • Weather strip atop the main frame.
  • Stainless steel clad low-profile threshold (depending on application, section can be varied to suit).
  • 6mm thick anti-pry bar to door and main frame (or passive door for doubles) to resist "jemmy bar" access.
  • All door chassis and main frame joints are fully welded, with the facing sheet, mid panel and anti-pry bars stitch-welded to the door chassis and mid transom.
  • Fixed to surrounds with 10mm diameter frame anchors.
  • Double door passive leaf secured by concealed stainless steel drop bolts (cannot be disengaged when doors are closed).



Finish



Configuration Options

Doors can be supplied:



  • Left or right handed.
  • Inward or outward opening.
  • With any combination of furniture. Please refer to our furniture options.
  • Single, double, top panel(s), side panel etc. Please refer to our configuration options (pdf).
  • With frame extensions (cheeks) or architrave to minimise/negate further works to finish the door opening.



Applications

Generally used by local authorities, hospitals, schools, care homes, municipal buildings, offices etc.
